Cellulose cooler EC 0750 B

699,930,000 $

16 in stock

Description

  • Intelligent change of the cool air flow rate according to the desired temperature using BLDC motor and drive in thermostatic mode
  • Providing more ventilation in long ducts or smaller dimensions than standard with the help of drive and control panel
  • Achievement of thermal comfort temperature in a short time
  • Low-noise operation within the set temperature range and maintaining thermal comfort conditions with minimum motor speed intelligently
  • Reducing electricity consumption by up to 60% and water by up to 30% using thermostat, BLDC motor and drive
  • Ability to adjust the fan at 20 different speeds
  • Touch control panel with color display with manual and automatic operation with remote control
  • Electromotor with copper coil and cooler performance with high protection class (IP64)
  • Equipped with comb drain for uniform water distribution and no dry area on the cellulose pad
  • Easy assembly and disassembly and strength of the cooler body using thick galvanized sheet
  • Equipped with EMI noise suppressor and ability to start the cooler in voltage fluctuations from 185 to 245 volts
  • Supply of fresh air with minimal adjustment Fan speed in temperate seasons
  • RCCB safety control Residual current circuit breaker and double pole disconnect switch

Technical specifications

Evaporation EfficiencyAeration Rate
Technical Specifications Unit EC0750B
cooling system evaporative
Cellulose Pad Thickness Centimeters 7.5
% 85
Cubic Feet Per Minute (Cubic Meters Per Hour) 4410(7500)
Coolable surface (approximate) Sq m 90-150
Electromotor power Horsepower(kW) 3/4(0/56)
Electrical specifications Phase, voltage, Amps 0/6-2/1,220,1
Product weight+ (water weight) Kilograms 86+50
Dimensions(width*length*height) Centimeters 111*90*90
Maximum channel length meters 25
Air projectile rate meters
